Home > Fasteners > Nuts > Hexagonal nuts > DIN 934.10 FP BL

DIN 934.10 FP BL

ISO 4032

Hexagonal nut with fine pitch thread in black finish and quality 10

Ref.: 6600200

It is a hexagonal nut with ISO 4032 equivalence, fine pitch, manufactured in quality 10 and with black coating. Its design is smooth finish and threaded on the inside. It is used to secure the fastening of screws.

Size	Code	Pcs. Box	KG Box	PCS. Master	KG Master	PCS. Pallet	KG Pallet	EAN Box	Weight (Pc/Kg)	Technical Info.
Size	Code	Pcs. Box	KG Box	PCS. Master	KG Master	PCS. Pallet	KG Pallet	EAN Box	Weight (Pc/Kg)	Technical Info.
M8 x 1,00	660020008X1,00	500	2.65	4.000	21.2	144.000	763.2	8432569294033	0.0053
	M8 e14,38 m6,8/6,5 S13
M10 x 1,00	660020010X1,00	200	2.3	1.600	18.4	57.600	662.4	8432569294040	0.0115
	M10 e18,9/17,77 m8/8,4 S17/16
M10 x 1,25	660020010X1,25	200	2.28	1.600	18.24	57.600	656.64	8432569294057	0.0114
	M10 e18,9/17,77 m8/8,4 S17/16
M12 x 1,25	660020012X1,25	200	3.4	1.200	20.4	43.200	734.4	8432569294071	0.017
	M12 e21,1/20,03 m10/10,8 S19/18
M12 x 1,50	660020012X1,50	200	3.44	1.200	20.64	43.200	743.04	8432569294088	0.0172
	M12 e21,1/20,03 m10/10,8 S19/18
M14 x 1,50	660020014X1,50	200	4.9	800	19.6	28.800	705.6	8432569294095	0.0245
	M14 e24,49/23,36 m11/12,8 S22/21
M16 x 1,50	660020016X1,50	100	3.26	600	19.56	21.600	704.16	8432569294101	0.0326
	M16 e26,75 m13/14,8 S24
M18 x 1,50	660020018X1,50	100	4.72	400	18.88	14.400	679.68	8432569294118	0.0472
	M18 e29,56 m15/15,8 S27
M20 x 1,50	660020020X1,50	50	3.115	300	18.69	10.800	672.84	8432569294125	0.0623
	M20 e32,95 m16/18 S30
M22 x 1,50	660020022X1,50	50	3.785	200	15.14	7.200	545.04	8432569294132	0.0757
	M22 e35,03/37,29 m18/19,4 S32/34
M22 x 2,00	660020022X2,00	50	3.95	200	15.8	7.200	568.8	8432569294149	0.079
	M22 e35,03/37,29 m18/19,4 S32/34
M24 x 1,50	660020024X1,50	50	5.25	200	21	7.200	756	8432569294156	0.105
	M24 e39,55 m19/21,5 S36
M24 x 2,00	660020024X2,00	50	5.3	200	21.2	7.200	763.2	8432569294163	0.106
	M24 e39,55 m19/21,5 S36
M27 x 2,00	660020027X2,00	25	4.125	100	16.5	3.600	594	8432569294187	0.165
	M27 e45,2 m22/23,8 S41
M30 x 2,00	660020030X2,00	25	5.525	75	16.575	2.700	596.7	8432569294194	0.221
	M30 e50,85 m24/25,6 S46
M33 x 2,00	660020033X2,00	10	2.79	60	16.74	2.160	602.64	8432569644265	0.279
	M33 e55,37 m26/28,7 S50
M36 x 3,00	660020036X3,00	10	3.87	40	15.48	1.440	557.28	8432569294200	0.387
	M36 e60,79 m29/31 S55
M39 x 3,00	660020039X3,00	-	0	40	19.68	1.440	708.48	8432569294224	0.492
	M39 e66,44 m31/33,4 S60
M42 x 3,00	660020042X3,00	-	0	35	22.26	1.260	801.36	8432569294248	0.636
	M42 e71,3 m34 S65
M45 x 3,00	660020045X3,00	-	0	27	21.06	972	758.16	8432569644272	0.78
	M45 e76,95 m36 S70
M48 x 3,00	660020048X3,00	-	0	20	18.98	720	683.28	8432569294255	0.949
	M48 e82,6 m38 S75
M52 x 3,00	660020052X3,00	-	0	18	21.24	648	764.64	8432569644289	1.18
	M52 e88,25 m42 S80
M8 x 1	20RD0020008X1,00	200	1.06	3.200	16.96	115.200	610.56	8445222365827	0.0053

M10 x 1	20RD0020010X1,00	100	1.15	1.600	18.4	57.600	662.4	8445222365834	0.0115

M10 x 1,25	20RD0020010X1,25	100	1.14	1.600	18.24	57.600	656.64	8445222365841	0.0114

M12 x 1,25	20RD0020012X1,25	100	1.7	1.600	27.2	57.600	979.2	8445222365865	0.017

M12 x 1,5	20RD0020012X1,50	100	1.72	1.600	27.52	57.600	990.72	8445222365872	0.0172

M14 x 1,5	20RD0020014X1,50	50	1.225	800	19.6	28.800	705.6	8445222365889	0.0245

M16 x 1,5	20RD0020016X1,50	50	1.63	800	26.08	28.800	938.88	8445222365896	0.0326

M18 x 1,5	20RD0020018X1,50	50	2.36	500	23.6	18.000	849.6	8445222365902	0.0472

M20 x 1,5	20RD0020020X1,50	25	1.5575	400	24.92	14.400	897.12	8445222365919	0.0623

M22 x 1,5	20RD0020022X1,50	25	1.8925	250	18.925	9.000	681.3	8445222365926	0.0757

M22 x 2	20RD0020022X2,00	25	1.975	250	19.75	9.000	711	8445222365933	0.079

M24 x 1,5	20RD0020024X1,50	20	2.1	160	16.8	5.760	604.8	8445222365940	0.105

M24 x 2	20RD0020024X2,00	20	2.12	160	16.96	5.760	610.56	8445222365957	0.106

M27 x 2	20RD0020027X2,00	20	3.3	160	26.4	5.760	950.4	8445222365971	0.165

M30 x 2	20RD0020030X2,00	20	4.42	80	17.68	2.880	636.48	8445222365988	0.221

M33 x 2	20RD0020033X2,00	10	2.79	40	11.16	1.440	401.76	8445222365995	0.279

M36 x 3	20RD0020036X3,00	10	3.87	40	15.48	1.440	557.28	8445222366022	0.387

M39 x 3	20RD0020039X3,00	5	2.46	40	19.68	1.440	708.48	8445222366046	0.492

M42 x 3	20RD0020042X3,00	5	3.18	20	12.72	720	457.92	8445222366060	0.636

M45 x 3	20RD0020045X3,00	5	3.9	20	15.6	720	561.6	8445222366077	0.78

M48 x 3	20RD0020048X3,00	-		-		-

M52 x 3	20RD0020052X3,00	-		-		-
