DIN 84 A2

ISO 1207

Slotted cheese head screw in stainless Steel A2

Ref.: 6121050

It is an ISO 1207 equivalent cylindrical head bolt manufactured from A2 stainless steel offering corrosion resistance and durability. It is a full thread design with a slotted tread.

Size	Code	Pcs. Box	KG Box	PCS. Master	KG Master	PCS. Pallet	KG Pallet	EAN Box	Weight (Pc/Kg)	Technical Info.
Size	Code	Pcs. Box	KG Box	PCS. Master	KG Master	PCS. Pallet	KG Pallet	EAN Box	Weight (Pc/Kg)	Technical Info.
M3 x 5	612105003X005	2.000	1.12	60.000	33.6	2.160.000	1209.6	8432569753783	0.00056
	M3 L5 k2 dk5,5 b25 n0,8 t0,85
M3 x 6	612105003X006	2.000	1.2	32.000	19.2	1.152.000	691.2	8432569279825	0.0006
	M3 L6 k2 dk5,5 b25 n0,8 t0,85
M3 x 8	612105003X008	2.000	1.4	32.000	22.4	1.152.000	806.4	8432569279832	0.0007
	M3 L8 k2 dk5,5 b25 n0,8 t0,85
M3 x 10	612105003X010	2.000	1.6	32.000	25.6	1.152.000	921.6	8432569279849	0.0008
	M3 L10 k2 dk5,5 b25 n0,8 t0,85
M3 x 12	612105003X012	2.000	1.6	16.000	12.8	576.000	460.8	8432569279856	0.0008
	M3 L12 k2 dk5,5 b25 n0,8 t0,85
M3 x 16	612105003X016	2.000	2	16.000	16	576.000	576	8432569279863	0.001
	M3 L16 k2 dk5,5 b25 n0,8 t0,85
M3 x 20	612105003X020	2.000	2.4	16.000	19.2	576.000	691.2	8432569279870	0.0012
	M3 L20 k2 dk5,5 b25 n0,8 t0,85
M3 x 25	612105003X025	2.000	2.8	16.000	22.4	576.000	806.4	8432569279887	0.0014
	M3 L25 k2 dk5,5 b25 n0,8 t0,85
M3 x 30	612105003X030	2.000	3.2	8.000	12.8	288.000	460.8	8432569279894	0.0016
	M3 L30 k2 dk5,5 b25 n0,8 t0,85
M3 x 35	612105003X035	2.000	3.76	8.000	15.04	288.000	541.44	8432569745818	0.00188
	M3 L35 k2 dk5,5 b25 n0,8 t0,85
M3 x 40	612105003X040	1.000	2.1	4.000	8.4	144.000	302.4	8432569520606	0.0021
	M3 L40 k2 dk5,5 b25 n0,8 t0,85
M3 x 50	612105003X050	1.000	2.4	4.000	9.6	144.000	345.6	8432569745825	0.0024
	M3 L50 k2 dk5,5 b25 n0,8 t0,85
M4 x 6	612105004X006	2.000	2.2	16.000	17.6	576.000	633.6	8432569279900	0.0011
	M4 L6 k2,6 dk7 b38 n1,2 t1,1
M4 x 8	612105004X008	2.000	2.6	8.000	10.4	288.000	374.4	8432569279917	0.0013
	M4 L8 k2,6 dk7 b38 n1,2 t1,1
M4 x 10	612105004X010	2.000	3	8.000	12	288.000	432	8432569279924	0.0015
	M4 L10 k2,6 dk7 b38 n1,2 t1,1
M4 x 12	612105004X012	2.000	3.2	8.000	12.8	288.000	460.8	8432569279931	0.0016
	M4 L12 k2,6 dk7 b38 n1,2 t1,1
M4 x 14	612105004X014	2.000	3.58	8.000	14.32	288.000	515.52	8432569728361	0.00179
	M4 L14 k2,6 dk7 b38 n1,2 t1,1
M4 x 16	612105004X016	2.000	3.8	8.000	15.2	288.000	547.2	8432569279948	0.0019
	M4 L16 k2,6 dk7 b38 n1,2 t1,1
M4 x 20	612105004X020	2.000	4.4	8.000	17.6	288.000	633.6	8432569279955	0.0022
	M4 L20 k2,6 dk7 b38 n1,2 t1,1
M4 x 25	612105004X025	1.000	2.6	8.000	20.8	288.000	748.8	8432569279962	0.0026
	M4 L25 k2,6 dk7 b38 n1,2 t1,1
M4 x 30	612105004X030	1.000	3	4.000	12	144.000	432	8432569279979	0.003
	M4 L30 k2,6 dk7 b38 n1,2 t1,1
M4 x 35	612105004X035	1.000	3.4	4.000	13.6	144.000	489.6	8432569279986	0.0034
	M4 L35 k2,6 dk7 b38 n1,2 t1,1
M4 x 40	612105004X040	1.000	3.8	4.000	15.2	144.000	547.2	8432569279993	0.0038
	M4 L40 k2,6 dk7 b38 n1,2 t1,1
M4 x 50	612105004X050	1.000	4.57	4.000	18.28	144.000	658.08	8432569562262	0.00457
	M4 L50 k2,6 dk7 b38 n1,2 t1,1
M4 x 60	612105004X060	500	2.7	2.000	10.8	72.000	388.8	8432569280005	0.0054
	M4 L60 k2,6 dk7 b38 n1,2 t1,1
M5 x 8	612105005X008	500	1.1	4.000	8.8	144.000	316.8	8432569280012	0.0022
	M5 L8 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 10	612105005X010	500	1.25	4.000	10	144.000	360	8432569280029	0.0025
	M5 L10 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 12	612105005X012	500	1.4	4.000	11.2	144.000	403.2	8432569280036	0.0028
	M5 L12 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 14	612105005X014	500	1.525	4.000	12.2	144.000	439.2	8432569744972	0.00305
	M5 L14 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 16	612105005X016	500	1.65	4.000	13.2	144.000	475.2	8432569280050	0.0033
	M5 L16 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 20	612105005X020	500	1.9	4.000	15.2	144.000	547.2	8432569280067	0.0038
	M5 L20 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 25	612105005X025	500	2.2	4.000	17.6	144.000	633.6	8432569280074	0.0044
	M5 L25 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 30	612105005X030	500	2.5	4.000	20	144.000	720	8432569280081	0.005
	M5 L30 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 35	612105005X035	500	2.8	2.000	11.2	72.000	403.2	8432569280098	0.0056
	M5 L35 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 40	612105005X040	500	3.1	2.000	12.4	72.000	446.4	8432569280104	0.0062
	M5 L40 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 50	612105005X050	500	3.75	2.000	15	72.000	540	8432569280128	0.0075
	M5 L50 k3,3 dk8,5 b38 n1,2 t1,3
M5 x 60	612105005X060	500	4.35	1.000	8.7	36.000	313.2	8432569280135	0.0087
	M5 L60 k3,3 dk8,5 b38 n1,2 t1,3
M6 x 8	612105006X008	1.000	3.56	4.000	14.24	144.000	512.64	8432569650266	0.00356
	M6 L8 k3,9 dk10 b38 n1,6 t1,6
M6 x 10	612105006X010	1.000	3.9	4.000	15.6	144.000	561.6	8432569280166	0.0039
	M6 L10 k3,9 dk10 b38 n1,6 t1,6
M6 x 12	612105006X012	1.000	4.3	4.000	17.2	144.000	619.2	8432569280173	0.0043
	M6 L12 k3,9 dk10 b38 n1,6 t1,6
M6 x 14	612105006X014	1.000	4.62	4.000	18.48	144.000	665.28	8432569744989	0.00462
	M6 L14 k3,9 dk10 b38 n1,6 t1,6
M6 x 16	612105006X016	1.000	5	4.000	20	144.000	720	8432569280180	0.005
	M6 L16 k3,9 dk10 b38 n1,6 t1,6
M6 x 20	612105006X020	500	2.85	2.000	11.4	72.000	410.4	8432569280197	0.0057
	M6 L20 k3,9 dk10 b38 n1,6 t1,6
M6 x 25	612105006X025	500	3.25	2.000	13	72.000	468	8432569280203	0.0065
	M6 L25 k3,9 dk10 b38 n1,6 t1,6
M6 x 30	612105006X030	500	3.7	2.000	14.8	72.000	532.8	8432569280210	0.0074
	M6 L30 k3,9 dk10 b38 n1,6 t1,6
M6 x 35	612105006X035	500	4.15	2.000	16.6	72.000	597.6	8432569280227	0.0083
	M6 L35 k3,9 dk10 b38 n1,6 t1,6
M6 x 40	612105006X040	500	4.6	2.000	18.4	72.000	662.4	8432569280234	0.0092
	M6 L40 k3,9 dk10 b38 n1,6 t1,6
M6 x 50	612105006X050	200	2.18	1.600	17.44	57.600	627.84	8432569280258	0.0109
	M6 L50 k3,9 dk10 b38 n1,6 t1,6
M6 x 60	612105006X060	200	2.54	1.600	20.32	57.600	731.52	8432569280265	0.0127
	M6 L60 k3,9 dk10 b38 n1,6 t1,6
M3 x 5	20RX2105003X005	1.000	0.56	30.000	16.8	1.080.000	604.8	8445222302051	0.00056

M3 x 6	20RX2105003X006	1.000	0.6	30.000	18	1.080.000	648	8445222302068	0.0006

M3 x 8	20RX2105003X008	1.000	0.7	30.000	21	1.080.000	756	8445222302075	0.0007

M3 x 10	20RX2105003X010	1.000	0.8	30.000	24	1.080.000	864	8445222302082	0.0008

M3 x 12	20RX2105003X012	1.000	0.8	16.000	12.8	576.000	460.8	8445222302099	0.0008

M3 x 16	20RX2105003X016	1.000	1	16.000	16	576.000	576	8445222302112	0.001

M3 x 20	20RX2105003X020	500	0.6	15.000	18	540.000	648	8445222302129	0.0012

M3 x 25	20RX2105003X025	500	0.7	15.000	21	540.000	756	8445222302136	0.0014

M3 x 30	20RX2105003X030	500	0.8	8.000	12.8	288.000	460.8	8445222302143	0.0016

M3 x 35	20RX2105003X035	500	0.94	8.000	15.04	288.000	541.44	8445222302150	0.00188

M3 x 40	20RX2105003X040	500	1.05	8.000	16.8	288.000	604.8	8445222302167	0.0021

M3 x 50	20RX2105003X050	500	1.2	5.000	12	180.000	432	8445222302174	0.0024

M4 x 6	20RX2105004X006	500	0.55	15.000	16.5	540.000	594	8445222302204	0.0011

M4 x 8	20RX2105004X008	500	0.65	15.000	19.5	540.000	702	8445222302211	0.0013

M4 x 10	20RX2105004X010	500	0.75	15.000	22.5	540.000	810	8445222302228	0.0015

M4 x 12	20RX2105004X012	500	0.8	10.000	16	360.000	576	8445222302235	0.0016

M4 x 16	20RX2105004X016	500	0.95	8.000	15.2	288.000	547.2	8445222302259	0.0019

M4 x 20	20RX2105004X020	500	1.1	8.000	17.6	288.000	633.6	8445222302266	0.0022

M4 x 25	20RX2105004X025	500	1.3	8.000	20.8	288.000	748.8	8445222302273	0.0026

M4 x 30	20RX2105004X030	500	1.5	8.000	24	288.000	864	8445222302280	0.003

M4 x 35	20RX2105004X035	500	1.7	8.000	27.2	288.000	979.2	8445222302297	0.0034

M4 x 40	20RX2105004X040	250	0.95	4.000	15.2	144.000	547.2	8445222302303	0.0038

M4 x 45	20RX2105004X045	-		-		-

M4 x 50	20RX2105004X050	250	1.1425	2.500	11.425	90.000	411.3	8445222302327	0.00457

M4 x 60	20RX2105004X060	250	1.35	2.000	10.8	72.000	388.8	8445222302334	0.0054

M5 x 8	20RX2105005X008	250	0.55	7.500	16.5	270.000	594	8445222302358	0.0022

M5 x 10	20RX2105005X010	250	0.625	7.500	18.75	270.000	675	8445222302365	0.0025

M5 x 12	20RX2105005X012	250	0.7	5.000	14	180.000	504	8445222302372	0.0028

M5 x 16	20RX2105005X016	250	0.825	5.000	16.5	180.000	594	8445222302402	0.0033

M5 x 20	20RX2105005X020	250	0.95	4.000	15.2	144.000	547.2	8445222302419	0.0038

M5 x 25	20RX2105005X025	250	1.1	4.000	17.6	144.000	633.6	8445222302426	0.0044

M5 x 30	20RX2105005X030	250	1.25	4.000	20	144.000	720	8445222302433	0.005

M5 x 35	20RX2105005X035	250	1.4	4.000	22.4	144.000	806.4	8445222302440	0.0056

M5 x 40	20RX2105005X040	250	1.55	4.000	24.8	144.000	892.8	8445222302457	0.0062

M5 x 45	20RX2105005X045	-		-		-

M5 x 50	20RX2105005X050	250	1.875	2.000	15	72.000	540	8445222302471	0.0075

M5 x 60	20RX2105005X060	250	2.175	2.000	17.4	72.000	626.4	8445222302488	0.0087

M5 x 70	20RX2105005X070	-		-		-

M5 x 80	20RX2105005X080	-		-		-

M6 x 10	20RX2105006X010	250	0.975	5.000	19.5	180.000	702	8445222302532	0.0039

M6 x 12	20RX2105006X012	250	1.075	5.000	21.5	180.000	774	8445222302549	0.0043

M6 x 16	20RX2105006X016	250	1.25	5.000	25	180.000	900	8445222302570	0.005

M6 x 20	20RX2105006X020	250	1.425	4.000	22.8	144.000	820.8	8445222302587	0.0057

M6 x 25	20RX2105006X025	250	1.625	2.500	16.25	90.000	585	8445222302594	0.0065

M6 x 30	20RX2105006X030	250	1.85	2.500	18.5	90.000	666	8445222302600	0.0074

M6 x 35	20RX2105006X035	250	2.075	2.000	16.6	72.000	597.6	8445222302617	0.0083

M6 x 40	20RX2105006X040	250	2.3	2.000	18.4	72.000	662.4	8445222302624	0.0092

M6 x 45	20RX2105006X045	-		-		-

M6 x 50	20RX2105006X050	200	2.18	1.600	17.44	57.600	627.84	8445222302648	0.0109

M6 x 60	20RX2105006X060	200	2.54	800	10.16	28.800	365.76	8445222302655	0.0127

M6 x 70	20RX2105006X070	-		-		-

M6 x 80	20RX2105006X080	-		-		-

M8 x 16	20RX2105008X016	-		-		-

M8 x 20	20RX2105008X020	-		-		-

M8 x 25	20RX2105008X025	-		-		-

M8 x 30	20RX2105008X030	-		-		-

M8 x 35	20RX2105008X035	-		-		-

M8 x 40	20RX2105008X040	-		-		-

M8 x 45	20RX2105008X045	-		-		-

M8 x 50	20RX2105008X050	-		-		-

M8 x 60	20RX2105008X060	-		-		-

M10 x 20	20RX2105010X020	-		-		-

M10 x 25	20RX2105010X025	-		-		-

M10 x 30	20RX2105010X030	-		-		-

M10 x 35	20RX2105010X035	-		-		-

M10 x 40	20RX2105010X040	-		-		-

M10 x 45	20RX2105010X045	-		-		-

M10 x 50	20RX2105010X050	-		-		-

M10 x 60	20RX2105010X060	-		-		-

M10 x 70	20RX2105010X070	-		-		-

M10 x 80	20RX2105010X080	-		-		-
