DIN 435

Plain square taper washer for U-beams with 14% slope

Ref.: 1201630
It is a wedge washer without bath made of HV 100 quality. It has a square design with a 14% inclined angle. It is used for U-profiles that need levelling and adjustment of surface unevenness.
SizeCodePcs. BoxKG BoxPCS. MasterKG MasterPCS. PalletKG PalletEAN BoxWeight (Pc/Kg)Technical Info.
SizeCodePcs. BoxKG BoxPCS. MasterKG MasterPCS. PalletKG PalletEAN BoxWeight (Pc/Kg)Technical Info.
M10 - I11,5 1201630M-10/I-11,5 200 1.88 2.400 22.56 86.400 812.16 8432569471717 0.0094
  • M10
  • a22
  • b22
  • d11
  • h4,6
  • t0,5
M12 - I14 1201630M-12/I-14,0 100 2.01 800 16.08 28.000 562.8 8432569471724 0.0201
  • M12
  • a26
  • b30
  • d13,5
  • h6,2
  • t0,7
M16 - I18 1201630M-16/I-18,0 100 3.56 600 21.36 21.600 768.96 8432569471748 0.0356
  • M16
  • a32
  • b36
  • d17,5
  • h7,5
  • t0,8
M20 - I23 1201630M-20/I-23,0 100 6.7 600 40.2 21.600 1447.2 8432569471762 0.067
  • M20
  • a40
  • b44
  • d22
  • h9,2
  • t0,9
M10 - I11,5 20RX01630M-10/I-11,5 200 1.88 2.000 18.8 72.000 676.8 8445222285651 0.0094
M12 - I14 20RX01630M-12/I-14,0 100 2.01 1.000 20.1 36.000 723.6 8445222285668 0.0201
M16 - I18 20RX01630M-16/I-18,0 100 3.56 800 28.48 28.800 1025.28 8445222285682 0.0356
M20 - I23 20RX01630M-20/I-23,0 100 6.7 400 26.8 14.400 964.8 8445222285705 0.067
