Other nuts

DIN 929 A2

Plain square weld nut. Stainless steel A2

Ref.: 6624900
It is a weldable hex nut made of A2 stainless steel offering corrosion resistance and durability. It is used for welding tasks.
Size Code Pcs. Box PCS. Master Uds. Palé EAN Box Weight (Pc/Kg) Technical Information
M5 662490005 0 8.000 288.000 8432569788327 0.00173
  • M5
  • M('')5
  • b0,8
  • d17
  • e10,95
  • m4
  • h10,7
  • h20,4
  • S10
M6 662490006 0 8.000 288.000 8432569788334 0.0025
  • M6
  • M('')6
  • b0,9
  • d18
  • e12,02
  • m5
  • h10,75
  • h20,4
  • S11
M8 662490008 0 4.000 144.000 8432569310122 0.0052
  • M8
  • M('')8
  • b1
  • d110,5
  • e15,38
  • m6,5
  • h10,9
  • h20,5
  • S14
M10 662490010 0 1.600 57.600 8432569564525 0.00958
  • M10
  • M('')10
  • b1,25
  • d112,5
  • e18,74
  • m8
  • h11,15
  • h20,65
  • S17
M12 662490012 0 1.600 57.600 8432569788341 0.0125
  • M12
  • M('')12
  • b1,25
  • d114,8
  • e20,91
  • m10
  • h11,4
  • h20,8
  • S19
