Other washers

DIN 6798 A ZP

Toothed lock washer external teeth form "A" in zinc plated finish

Ref.: 1106261
It is an external serrated washer with a black-oxide coating. It is used to immobilise connecting elements that are subject to vibration.

Check availability with our sales team.

SizeCodePcs. BoxKG BoxPCS. MasterKG MasterPCS. PalletKG PalletEAN BoxWeight (Pc/Kg)Technical Info.
SizeCodePcs. BoxPCS. MasterEAN BoxWeight (Pc/Kg)Technical Info.
M3 110626103 2.000 0.14 - 0 - 0 8432569018202 0.00007
  • M3
  • d13,2
  • d26
  • S0,4
M4 110626104 2.000 0.2 - 0 - 0 8432569018219 0.0001
  • M4
  • d14,3
  • d28
  • S0,5
M5 110626105 1.000 0.17 - 0 - 0 8432569018226 0.00017
  • M5
  • d15,3
  • d210
  • S0,6
M6 110626106 1.000 0.32 - 0 - 0 8432569018233 0.00032
  • M6
  • d16,4
  • d211
  • S0,7
M8 110626108 1.000 0.59 - 0 - 0 8432569018257 0.00059
  • M8
  • d18,4
  • d215
  • S0,8
M10 110626110 1.000 1.15 - 0 - 0 8432569018264 0.00115
  • M10
  • d110,5
  • d218
  • S0,9
M12 110626112 1.000 1.37 - 0 - 0 8432569018271 0.00137
  • M12
  • d112,5
  • d220,5
  • S1
M14 110626114 500 1.03 - 0 - 0 8432569018288 0.00206
  • M14
  • d114,5
  • d224
  • S1
M16 110626116 500 1.43 - 0 - 0 8432569018295 0.00286
  • M16
  • d116,5
  • d226
  • S1,2
M18 110626118 250 1.1225 - 0 - 0 8432569018301 0.00449
  • M18
  • d119
  • d230
  • S1,4
M20 110626120 250 1.4225 - 0 - 0 8432569018318 0.00569
  • M20
  • d121
  • d233
  • S1,4
M22 110626122 200 1.224 - 0 - 0 8432569018325 0.00612
  • M22
  • d123
  • d236
  • S1,5
M24 110626124 150 1.08 - 0 - 0 8432569018332 0.0072
  • M24
  • d125
  • d238
  • S1,5
M3 20RX0626103 2.000 60.000 8445222286825 0.00007
M4 20RX0626104 2.000 60.000 8445222286832 0.0001
M5 20RX0626105 1.000 30.000 8445222286849 0.00017
M6 20RX0626106 1.000 20.000 8445222286856 0.00032
M7 20RX0626107 1.000 16.000 8445222286863 0.00045
M8 20RX0626108 1.000 10.000 8445222286870 0.00059
M10 20RX0626110 1.000 8.000 8445222286887 0.00115
M12 20RX0626112 1.000 4.000 8445222286894 0.00137
M14 20RX0626114 500 2.000 8445222286900 0.00206
M16 20RX0626116 500 2.000 8445222286917 0.00286
M18 20RX0626118 250 2.000 8445222286924 0.00449
M20 20RX0626120 250 1.000 8445222286931 0.00569
M22 20RX0626122 200 800 8445222286948 0.00612
M24 20RX0626124 150 600 8445222286955 0.0072
M27 20RX0626127 - -
M30 20RX0626130 - -
